截止阀生产线 3D 模型

描述

according to the actual operation area of the customer, the manual and automatic design is adopted under the condition of meeting the production requirements. through manual auxiliary operation, automatic operation and automatic detection, the production needs of high efficiency and high quality are realized. the production line is composed of auxiliary production line and automatic assembly line, with automatic interception, unqualified sorting system and automatic assembly system. the measurement system consists of leakage detection system, electrical performance monitoring system and flow detection system. the production line is designed with artificial auxiliary worktable and assembly line, with a total length of 6.4 meters and a width of 4.4 meters. the circular assembly line and accompanying tooling are adopted to save space, facilitate product turnover and avoid being stuck. in addition to the manual auxiliary station, the product is transported through the assembly line. according to the assembly and inspection sequence, corresponding stations are set along the line. due to the variety of water cut-off valve types, the production line can meet or be compatible with the production needs of different types of water cut-off valves, so as to ensure the coordinated and unified production rhythm of the whole line. the operation space between each station is enough and practical, independent and connected with each other. 打印准备: 否
