कलेक्शन स्टैंडर्ड पुली शेव ट्रैक व्हील ड्राइव मल्टी ग्रूव 3D मॉडल

विवरण

High-quality 3D assets at affordable prices — trusted by designers, engineers, and creators worldwide. Made with care to be versatile, accessible, and ready for your pipeline.

Included File Formats
This model is provided in 14 widely supported formats, ensuring maximum compatibility:
• - FBX (.fbx) – Standard format for most 3D software and pipelines
• - OBJ + MTL (.obj, .mtl) – Wavefront format, widely used and compatible
• - STL (.stl) – Exported mesh geometry; may be suitable for 3D printing with adjustments
• - STEP (.step, .stp) – CAD format using NURBS surfaces
• - IGES (.iges, .igs) – Common format for CAD/CAM and engineering workflows (NURBS)
• - SAT (.sat) – ACIS solid model format (NURBS)
• - DAE (.dae) – Collada format for 3D applications and animations
• - glTF (.glb) – Modern, lightweight format for web, AR, and real-time engines
• - 3DS (.3ds) – Legacy format with broad software support
• - 3ds Max (.max) – Provided for 3ds Max users
• - Blender (.blend) – Provided for Blender users
• - SketchUp (.skp) – Compatible with all SketchUp versions
• - AutoCAD (.dwg) – Suitable for technical and architectural workflows
• - Rhino (.3dm) – Provided for Rhino users

Model Info
• - All files are checked and tested for integrity and correct content
• - Geometry uses real-world scale; model resolution varies depending on the product (high or low poly)
• • - Scene setup and mesh structure may vary depending on model complexity
• - Rendered using Luxion KeyShot
• - Affordable price with professional detailing

Buy with confidence. Quality and compatibility guaranteed.
If you have any questions about the file formats, feel free to send us a message — we're happy to assist you!

Sincerely,
SURF3D
Trusted source for professional and affordable 3D models.

More Information About 3D Model :
The designation "COLLECTION STANDARD PULLEY SHEAVE TRACK WHEEL DRIVE MULTI GROOVE" refers to a categorized inventory of standardized mechanical components specifically engineered for rotational power transmission and guided linear motion within industrial and heavy-duty machinery. These components are characterized by their adherence to common engineering standards (such as ISO, DIN, or ANSI) ensuring interchangeability, and critically, by the presence of multiple parallel grooves on their circumference designed to accommodate multiple power-transmitting elements simultaneously.

### I. Technical Classification and Function

The nomenclature encompasses three functionally distinct but structurally related component types often grouped together under standardized manufacturing specifications:

**1. Pulley/Sheave (Drive Component):**
These elements primarily function in drive systems utilizing flexible continuous loops—specifically V-belts, synchronous belts, or high-capacity cables. The defining characteristic is the **multi-groove** design, which serves several critical engineering purposes:

* **Load Distribution:** By utilizing multiple belts, the total tangential load is distributed across several points of contact, significantly increasing the overall power transmission capacity far beyond that of a single-belt system.
* **Reduced Slip:** Multiple contact surfaces enhance the effective coefficient of friction, minimizing slippage, which is crucial for maintaining speed ratios and drive efficiency.
* **Redundancy:** In high-stress applications, the failure or degradation of one belt does not necessarily lead to catastrophic system failure, allowing for temporary operation until maintenance can be performed.

Pulleys typically refer to components used with flat belts or timing belts, while the term **sheave** is often used in relation to V-belt systems or wire rope applications (e.g., cranes, hoists, and block-and-tackle systems).

**2. Track Wheel (Motion Guide Component):**
Track wheels, conversely, are designed not for power transmission via belts, but for load bearing and guiding systems. They operate by running along a fixed track, rail, or guiding channel. When categorized within this collection, they retain the multi-groove structure, though its function shifts from friction drive to controlled linear movement and stabilization.

* **Guidance and Indexing:** The multiple grooves or flanges ensure precise alignment and resist lateral displacement, crucial in indexing machinery, automated storage and retrieval systems (AS/RS), and conveyor trolleys.
* **Load Bearing:** They are engineered to sustain significant radial and axial loads while facilitating controlled, low-friction motion.

**3. Standardized Collection (Adherence):**
The term "Standard Collection" signifies that these components are manufactured according to rigorous dimensional specifications, often defined by pitch diameter, groove angle (for V-belts), bore size, hub configuration, and keyway dimensioning. This standardization is essential for global compatibility, ease of replacement, and the accurate calculation of speed reduction ratios (kinematics).

### II. Materials and Manufacturing

The selection of material is dictated by the required operational speeds, applied torque, environmental conditions, and desired service life.

* **Cast Iron (e.g., Grey Iron, Ductile Iron):** Common for heavy-duty, high-torque, and lower-speed multi-groove pulleys and large sheaves, offering excellent vibration damping and wear resistance.
* **Steel (e.g., Carbon Steel, Alloy Steel):** Used where maximum strength and resistance to shock loading are required, particularly for high-speed drive pulleys or robust track wheels.
* **Aluminum Alloys:** Employed in applications requiring lightweight components, reduced rotational inertia, and good heat dissipation, often finished with hard anodization.
* **Engineered Polymers:** Suitable for lighter loads, non-corrosive environments, and situations where noise reduction is paramount.

Manufacturing processes typically involve casting (for complex geometries), forging (for maximum strength), and precision CNC machining to achieve the necessary balance and concentricity critical for high-speed rotational operation. Dynamic balancing procedures are mandatory for ensuring safe operation and preventing vibration damage to adjacent bearing systems and shafts.

### III. Industrial Applications

Multi-groove standardized pulleys, sheaves, and track wheels are foundational elements in diverse industrial sectors:

* **Heavy Machinery:** Compressors, large pumps, motor-generator sets, and industrial fans where high horsepower must be transferred reliably.
* **Material Handling:** Main drive systems for long-distance conveyors, bucket elevators, and complex overhead gantry systems.
* **Automation and Robotics:** Precise motion control and heavy payload movement in automated factory environments utilizing track wheels for guidance.
* **Agricultural Equipment:** High-load drives for combine harvesters and large field machinery.

The incorporation of the multi-groove feature fundamentally elevates the maximum transmissible power density, making these components essential for robust and high-efficiency mechanical power transmission systems globally.

KEYWORDS: Power transmission, Multi-groove, Pulley, Sheave, Track Wheel, Drive component, Standardization, V-belt, Synchronous belt, Mechanical engineering, Load distribution, Industrial machinery, Conveyor systems, Precision guidance, Cast iron, Steel, Radial load, Axial load, Kinematics, Component collection, Indexing system, Flange, Bore, Pitch diameter, Balancing, Coefficient of friction, High efficiency, Rotational dynamics, Shaft coupling, ANSI/ISO.
