jet engine cfm56 international
3D 모델

simplified 3d model of cfm56 international jet engine (1:10 and 1:15).
3d print model.
cfm56 is a high-bypass turbofan engine (most of the air accelerated by the fan byp***** the core of the engine and is exhausted out of the fan case) with several variants having bypass ratios ranging from 5:1 to 6:1, generating 18,500 to 34,000 lbf (80 kn to 150 kn) of thrust.
developed in solidworks 2017.
converted to stl and stp (step) ready for 3d print.
m3 screws and glue are used for assembly
available formats: sldasm/sldprt, stl, step
