विद्युत विद्युत आपूर्ति नियंत्रण पैनल सॉकेट नियामक आउटलेट वीए 3D मॉडल

विवरण

High-quality 3D assets at affordable prices — trusted by designers, engineers, and creators worldwide. Made with care to be versatile, accessible, and ready for your pipeline.

Included File Formats
This model is provided in 14 widely supported formats, ensuring maximum compatibility:
• - FBX (.fbx) – Standard format for most 3D software and pipelines
• - OBJ + MTL (.obj, .mtl) – Wavefront format, widely used and compatible
• - STL (.stl) – Exported mesh geometry; may be suitable for 3D printing with adjustments
• - STEP (.step, .stp) – CAD format using NURBS surfaces
• - IGES (.iges, .igs) – Common format for CAD/CAM and engineering workflows (NURBS)
• - SAT (.sat) – ACIS solid model format (NURBS)
• - DAE (.dae) – Collada format for 3D applications and animations
• - glTF (.glb) – Modern, lightweight format for web, AR, and real-time engines
• - 3DS (.3ds) – Legacy format with broad software support
• - 3ds Max (.max) – Provided for 3ds Max users
• - Blender (.blend) – Provided for Blender users
• - SketchUp (.skp) – Compatible with all SketchUp versions
• - AutoCAD (.dwg) – Suitable for technical and architectural workflows
• - Rhino (.3dm) – Provided for Rhino users

Model Info
• - All files are checked and tested for integrity and correct content
• - Geometry uses real-world scale; model resolution varies depending on the product (high or low poly)
• • - Scene setup and mesh structure may vary depending on model complexity
• - Rendered using Luxion KeyShot
• - Affordable price with professional detailing

Buy with confidence. Quality and compatibility guaranteed.
If you have any questions about the file formats, feel free to send us a message — we're happy to assist you!

Sincerely,
SURF3D
Trusted source for professional and affordable 3D models.

More Information About 3D Model :
An Electrical Power Supply Control Panel incorporating integrated Socket Regulation and Distribution functionality (often designated by its maximum apparent power rating in Volt-Amperes, VA) is a specialized electrical apparatus designed for the precise monitoring, control, stabilization, and distribution of electrical energy to connected loads. This system is distinguished by its integration of human-machine interface (HMI) controls, power conditioning mechanisms, and standardized load connection points into a cohesive unit, typically mounted within a standardized enclosure (e.g., rack-mount chassis or industrial cabinet).

### Functional Definition and Architecture

The primary function of the apparatus is to manage power quality and output parameters. It serves as an intermediary between the primary utility power source or an uninterruptible power supply (UPS) and the end-user equipment (the load), ensuring that the energy delivered meets specific voltage, frequency, and current requirements.

### Control Panel Interface

The Control Panel component constitutes the operational and diagnostic interface. It provides operators with real-time feedback and adjustment capabilities.

1. **Metering:** Essential parameters are monitored via digital or analog displays, including Root Mean Square (RMS) voltage (V), current (A), apparent power (VA), real power (W), and often frequency (Hz). High-precision metering is standard for laboratory or testing environments.
2. **Indicators:** Status lights (LEDs) communicate system operational status, including power-on, fault conditions (e.g., overcurrent, overvoltage), regulator bypass mode, and grounding integrity.
3. **Controls:** The panel includes master power switches, circuit breakers for immediate disconnection, and fine-tuning controls (dials or push-buttons) for adjusting the output voltage level or regulation sensitivity.

### Power Regulation Mechanism

The Regulator is the core power conditioning element. Its function is to stabilize the output voltage against variations in the input source (line noise, brownouts) and fluctuations caused by load transients.

* **Types of Regulation:** Regulation systems vary based on required capacity and precision. These may include tap-switching automatic voltage regulators (AVR), magnetic saturation regulators, or solid-state devices utilizing thyristors (SCRs) or insulated-gate bipolar transistors (IGBTs) for high-speed, precise adjustments.
* **Variable Output:** In many applications, particularly laboratory testing or commissioning, the regulator allows for continuous manual or programmatic adjustment of the output voltage, sometimes utilizing a variable transformer (variac) integrated into the control circuitry.

### Socket and Outlet Distribution

The Socket or Outlet component refers to the standardized receptacles where the controlled electrical power is accessed by the load equipment. These outlets are electrically isolated from the main bus bar and are protected by individual or segmented overcurrent protection devices (fuses or miniaturized circuit breakers).

* **Safety Features:** Critical safety integration includes ground fault circuit interruption (GFCI) or residual current device (RCD) protection, which monitors imbalances between line and neutral currents, ensuring prompt disconnection upon detecting leakage or faults. The outlets must conform to regional standards (e.g., NEMA, IEC 60320, Schuko).

### VA Rating (Apparent Power Capacity)

The VA (Volt-Ampere) rating defines the maximum apparent power capacity of the entire unit—the theoretical maximum product of the voltage and current that the regulator and associated components can safely handle simultaneously. The VA rating is the fundamental determinant of the system’s size and cost, as it dictates the required gauge of internal wiring, the size of magnetic components (transformers), and the thermal dissipation capabilities of the enclosure. It is essential that the aggregate load connected to all sockets does not exceed the total VA rating of the panel to prevent overheating and component failure.

### Applications

This integrated control and distribution system is widely employed in environments requiring reliable, high-quality, and monitored power, including:

* **Calibration and Testing Laboratories:** Providing stable reference voltages for equipment calibration.
* **Industrial Automation:** Serving as the monitored power source for critical control logic or sensor arrays.
* **Research and Development:** Allowing engineers to test equipment across a range of operational voltages.
* **Data Centers:** Utilized as highly controlled power distribution units (PDUs) with integrated monitoring.

KEYWORDS: Electrical Power Supply, Control Panel, Voltage Regulator, Socket Outlet, Apparent Power, VA Rating, Power Distribution Unit, AVR, Load Monitoring, HMI Interface, Circuit Breaker, Overcurrent Protection, Ground Fault Circuit Interrupter, Power Conditioning, Industrial Control, Laboratory Equipment, System Integration, RMS Voltage, Current Metering, Variable Transformer, Rack Mount, Power Quality, Standardization, Electrical Safety, Transient Suppression, Energy Management, Power Factor, SCADA Integration, Load Transients, Output Stability.
