arc welding workstation with dual robots and double clamps Modello 3D

$10.00
Licenza:
arc welding workstation with dual robots and double clamps Modello 3D
$ 10.00
Rimuovi Segnalibro Segnala questo Oggetto
  • Animato:
    No
  • Textured:
    No
  • Rigged:
    No
  • Materiali:
    Yes
  • Low-poly:
    No
  • Collezione:
    No
  • Mapping UVW:
    No
  • Plugins Utilizzati:
    No
  • Stampa Pronta:
    No
  • 3D Scan:
    No
  • Per adulti:
    No
  • PBR:
    No
  • Geometria:
    Polygonal
  • UVs Aperti:
    Unknown
  • Visualizzazioni:
    2611
  • Data: 2020-09-29
  • ID Oggetto:
    314426
  • Voto:
Effettua un report di questo oggetto
the final assembly design of dual robot and dual fixture arc welding workstation includes parts and assembly drawing of catia modeling, stp file and bip rendering file. in the general assembly design of double robot and double fixture arc welding workstation, the two workstations are crossed, so that the robot welding time is synchronized with the workpiece loading and unloading time, which can save the positioner rotation time. in the welding robot system of double fixture slide rail, two pairs of slide rails can be used to feed the welding robot in turn. the fixture is shifted by the positioner to realize the welding of different positions of the robot welding. Stampa Pronta: No
Hai bisogno di ulteriori formati?
Se hai bisogno di diversi formati, aprire un nuovo Ticket i Supporto e una richiesta per questo. Convertiamo modelli 3D a: .stl, .c4d, .obj, .fbx, .ma/.mb, .3ds, .3dm, .dxf/.dwg, .max. .blend, .skp, .glb. Non convertiamo scene 3d e formati come .step, .iges, .stp, .sldprt.!

Scaricato arc welding workstation with dual robots and double clamps Modello 3D step catia Da tzd

welding
Nessun commento per quest'oggetto.
