FOLDING MOUNTED BED CRANE HOIST LIFTING HAND WINCH PICKUP TRUCK Model 3D

High-quality 3D assets at affordable prices — trusted by designers, engineers, and creators worldwide. Made with care to be versatile, accessible, and ready for your pipeline.

Included File Formats
This model is provided in 14 widely supported formats, ensuring maximum compatibility:
• - FBX (.fbx) – Standard format for most 3D software and pipelines
• - OBJ + MTL (.obj, .mtl) – Wavefront format, widely used and compatible
• - STL (.stl) – Exported mesh geometry; may be suitable for 3D printing with adjustments
• - STEP (.step, .stp) – CAD format using NURBS surfaces
• - IGES (.iges, .igs) – Common format for CAD/CAM and engineering workflows (NURBS)
• - SAT (.sat) – ACIS solid model format (NURBS)
• - DAE (.dae) – Collada format for 3D applications and animations
• - glTF (.glb) – Modern, lightweight format for web, AR, and real-time engines
• - 3DS (.3ds) – Legacy format with broad software support
• - 3ds Max (.max) – Provided for 3ds Max users
• - Blender (.blend) – Provided for Blender users
• - SketchUp (.skp) – Compatible with all SketchUp versions
• - AutoCAD (.dwg) – Suitable for technical and architectural workflows
• - Rhino (.3dm) – Provided for Rhino users

Model Info
• - All files are checked and tested for integrity and correct content
• - Geometry uses real-world scale; model resolution varies depending on the product (high or low poly)
• • - Scene setup and mesh structure may vary depending on model complexity
• - Rendered using Luxion KeyShot
• - Affordable price with professional detailing

Buy with confidence. Quality and compatibility guaranteed.
If you have any questions about the file formats, feel free to send us a message — we're happy to assist you!

Sincerely,
SURF3D
Trusted source for professional and affordable 3D models.

More Information About 3D Model :
A **Folding Mounted Bed Crane Hoist with Hand Winch Attached on a Pickup Truck**, commonly referred to as a pickup truck crane, truck bed crane, or davit crane, is a specialized piece of mobile material handling equipment. Designed for integration with the cargo bed of light-duty trucks, its primary function is to facilitate the manual lifting, lowering, and positioning of moderate loads, thereby enhancing the utility and operational versatility of the host vehicle. It distinguishes itself by its compact, collapsible design and reliance on manual power for lifting operations.

**Structural Components:**
The device typically comprises several key components:
1. **Crane Boom:** The primary arm that extends and retracts or folds to reach and lift loads. Its "folding" characteristic enables it to be stowed compactly when not in use, preserving valuable cargo space. Booms can be fixed, telescopic, or articulated via hinged sections.
2. **Mounting Base/Pedestal:** A robust structure engineered to securely attach the crane to the pickup truck's chassis or reinforced bed, ensuring stability during lifting. This base often incorporates a swivel mechanism, allowing the boom to rotate through a significant arc (e.g., 360 degrees) for precise load placement.
3. **Hand Winch:** The core lifting mechanism, consisting of a drum, a crank handle, and an internal gear system (such as worm or spur gears) that provides mechanical advantage. A steel cable or synthetic rope, terminated with a lifting hook, is wound onto or off the drum by manual rotation of the crank. Many hand winches include a load-holding brake for safety.
4. **Rigging Hardware:** Essential components like hooks, shackles, and chains used to connect the load securely to the crane's lifting line.

**Operational Mechanism:**
Operation involves unfolding or extending the crane boom from its stowed position. Once deployed, the operator attaches the winch hook to the load using appropriate rigging. The load is then raised by manually turning the hand winch handle, winding the cable onto the drum. After lifting, the boom and attached load can be rotated horizontally via the swivel base to maneuver the item into or out of the truck bed. Lowering is accomplished by reversing the winch operation, often controlled by a brake mechanism for precise descent. Upon completion, the boom is folded and secured for transport.

**Design and Material Considerations:**
These cranes are typically fabricated from high-strength steel (e.g., carbon or alloy steel) to ensure structural integrity and durability, often treated with corrosion-resistant coatings like powder coat or galvanization. The folding design is crucial for maximizing truck bed utility when the crane is not in active use. The mounting system is designed for secure, often bolt-on, installation, requiring careful consideration of the truck's frame or bed reinforcement to safely manage dynamic and static loads.

**Applications:**
The portability, cost-effectiveness, and independence from external power sources make this equipment highly valuable in various sectors:
* **Trades and Construction:** Plumbers, electricians, HVAC technicians, and general contractors utilize them for lifting tools, equipment (e.g., generators, compressors), and materials.
* **Agriculture and Landscaping:** Farmers and landscapers employ these cranes for handling feed sacks, small machinery components, fencing, rocks, trees, and other heavy agricultural or horticultural items.
* **Remote Maintenance:** Ideal for maintenance crews working in locations without access to electricity, facilitating the movement of pumps, motors, or spare parts.
* **Recreational Use:** Aiding in the loading and unloading of heavy recreational gear, engines, or generators for camping, hunting, or off-road excursions.

**Advantages:**
* **Mobility:** Provides mobile lifting capabilities directly integrated with the transport vehicle.
* **Cost Efficiency:** Generally more economical in acquisition and maintenance compared to hydraulic or electric crane systems.
* **Energy Independence:** Operates without requiring an external power supply, making it suitable for remote environments.
* **Simplicity:** Features a straightforward mechanical design, contributing to reliability and ease of repair.
* **Space Optimization:** The folding design allows for minimal encroachment on truck bed space when the crane is not in operation.

**Limitations and Safety:**
A primary limitation is the reliance on manual effort, which dictates a slower lifting speed and imposes a practical maximum load capacity (typically ranging from a few hundred to approximately 2,000 pounds, depending on the model). Safe operation is paramount and requires strict adherence to manufacturer's load limits, proper rigging techniques, and an understanding of the vehicle's stability. The truck must be parked on level ground, with the parking brake engaged, and any optional outriggers deployed to prevent tipping or instability during lifting operations. Regular inspection of all components, particularly the winch cable and hook, is essential.

**Variants:**
While this description focuses on the hand-winch variant, similar truck bed cranes are available with electric winches (powered by the vehicle's 12V system) or small hydraulic systems. These powered alternatives offer increased lifting capacity and reduced operator effort but introduce complexity and dependence on a power source.

KEYWORDS: Pickup truck crane, Truck bed crane, Davit crane, Hand winch, Lifting equipment, Material handling, Portable crane, Folding crane, Manual hoist, Vehicle-mounted crane, Utility crane, Cargo lift, On-site lifting, Telescopic boom, Swivel base, Load handling, Off-grid operations, Construction equipment, Farm equipment, Maintenance tool, Tradesman equipment, Mechanical advantage, Vehicle utility, Collapsible crane, Truck accessory, Heavy duty lift, Manual operation, Load capacity, Work truck, Field service
