three story villa 3-09 Model 3D

three story villa 3-09 Model 3D dwg, Od tzd

the unit type is single family single courtyard type, with a land area of 134.5 square meters, an area of 109.46 square meters, a building area of 298.36 square meters, and a building height of 11.835 meters (the highest roof ridge). the first floor is equipped with living room, dining room, kitchen, guest room, elderly room, heating room and toilet; the second floor is equipped with living room, master bedroom, secondary bedroom, guest room, children's room, toilet and a large terrace; the third floor is equipped with living room, three bedrooms, one bathroom and two large balconies;



the house adopts sloping roof, mixed structure, simple and generous appearance, bright color, suitable room scale design, high space utilization rate, moderate cost, and full of the flavor of the new rural era.



door width 13.8m * depth 8.34m



the fire resistance rating of the building is designed as grade ii, the main structural form is brick concrete structure, the design service life is 50 years, the safety level is grade ii, and the lightning protection is class iii.



the project is a two-story and half brick concrete structure, belonging to non seismic fortification area



the reference cost is 238000. Gotowy do wydruku: Nie
