automobile manual transmission mechanism gearbox 3D Model

$1000.00
automobile manual transmission mechanism gearbox 3D Model
$ 1000.00
Remove Bookmark Bookmark This Item
  • Available formats:
    Autodesk FBX: fbx 11.72 MB
    Lightwave ver. 7: lwo 5.06 MB
    Lightwave ver. 7: lwo 13.48 MB
    3DS MAX ver.2010: max2010 7.28 MB
    Rhinoceros: 3dm 9.06 MB
    ArchiCAD (native): dxf 13.24 MB
    Wavefront OBJ: obj 11.19 MB
    3DS MAX ver.2011: max2011 7.69 MB
    3DS MAX all ver.: 3ds 6.13 MB
    Cinema4D: c4d 2.82 MB
    Maya: mb 10.90 MB
    3DS MAX ver.2011: max2011 12.93 MB
  • Polygons:
    532,644
  • Vertices:
    501,078
  • Animated:
    No
  • Textured:
  • Rigged:
    No
  • Materials:
  • Geometry:
    Polygonal
  • Views:
    13408
  • Date:
  • Item ID:
    24996
  • Rating:
hallo everyone, i am a hardcore 3d enthusiast and this is my first post on this site.

this is a complete high quality design & model of an actual 5 speed manual transmission internal mechanism of an automobile in actual 1:1 scale. this is the model for transmission of power up to 295nm@3800rpm.
this model took me around 8 months to complete and over 50 different types of transmissions observations. it was created and tested using 3-4 different softwares like solidworks, pro-e, autocad and 3d studio max. the final assembly of the model is done in 3d studio max 2010. since it was created using many other softwares some object names may be starting or ending with 'nurbs'. but they are not nurb objects. 90% of the parts were created as solid model and then it was imported to 3ds max for final rendering.

- you will be amazed to see the detailing of the model.
- it contains lot more than you see in the rendering
- all the bearings, gears, forks etc. were individually designed and modeled.
- over 120 individually designed parts and total 728 to be precise.
- with fully textured in v-ray.
- number of textures are very less so even if you don't have v-ray you can texture it whatever you want.
- with number of formats available for use.
- other formats can be used in older versions also.
- the model is in array of different format so you can use it in whichever software you want.

the model is not animated but the zip file contains a video file of the animation of a simplified version of the model which shows the complete mechanism.
update :- now with complete outer housing

model statistics
objects :- 728
polygons: 501,078
vertices: 532,644

the zip file contains
the model in following formats
.max, .mb, .dxf, .dwg, .c4d, .3ds, .obj, .igs
mechanism video
materials
high-def renderings


license:-
i do not apply any custom license on this model so you can use and modify it as per your requirements. but there are some strict restrictions regarding reselling and remodeling and intellectual property rights. the model comes under these rules and regulations. for further questions regarding license please read the license agreement and ipr of the website.
Need more formats?
If you need a different format, please send us a Conversion Request. We can convert 3D models to: .stl, .c4d, .obj, .fbx, .ma/.mb, .3ds, .3dm, .dxf/.dwg, .max. .blend, .skp, .glb. We do not convert 3d scenes and solid formats such as .step, .iges, .stp, .sldprt etc!

Download automobile manual transmission mechanism gearbox 3D Model fbx lwo lwo max2010 3dm dxf obj max2011 3ds c4d mb max2011 From daveterminator

transmission gearbox
