Rc car chassis 3D Print Model

3d model of remote control car chassis 1/8 scale, can be printed.
when building the chassis, there is non-printable parts you need to buy, the parts list is below

this is 3d printed land rover discovery remote control car chassis (land rover discovery 5 body you can find in my portfolio) has independent front and rear suspension, 3 differentials, front, rear and center with the ability to lock them remotly, also has a 2-speed gearbox. the first speed is for crawling, the second is for "everyday" driving. you can change gears and block differentials remotely, from the transmitter, each differential can be controlled separately, this allows you to create interesting situations and observe how the mechanisms work). the body has a detailed car interior.

gear ratio:
gear ratio dif - 2.92 (differential from part list)
low gear - 23/10*20/10*42/10*gearratiodif=56.47 | gearbox - 19.32
high gear - 23/10*10/20*42/10*gearratiodif=14.11 | gearbox - 4.83

сhassis features:
• independent front and rear suspension
• remote locking 3 differentials, front, rear and center
• each differential can be controlled (lock/unlock) separately
• gearbox, 2-speed with neutral gear
• low center of gravity
• large suspension articulation
• modular design (the ability to use any wheelbase)

model dimensions:
width - 254 mm,
wheelbase - 367 mm


these dimensions are the same dimensions as the original land rover discovery 5 in 1/8 scale. in order not to disturb the proportions of the body and make the model more replica, i use the given wheelbase and width dimensions, and not the standard 313mm for trophies rc cars.

ASSEMBLY INSTRUCTIONS
https://www.youtube.com/watch?v=dgCt1rcEK2E&list=PLMRVq9hyLS0gWp-zClnDmKvLD1YTZa1nT







non-printable parts you need to buy to make remote contole car:

radiolink rc6gs 6 channel transmitter with r7fg receiver gyro telemetry - http://alii.pub/5uy1y9

motor 540 + pinion 10t 1m - http://alii.pub/5uy23i
esc hobbywing 1060 - http://alii.pub/5uy295
wheels dia 100mmx36mm - http://alii.pub/5v42kn

differentials + bearings - http://alii.pub/5uy2cn
4pcs shock absorber 100mm - http://alii.pub/5v40oz
4pcs aluminum steel shaft adjustable length - http://alii.pub/5v405c
or use plastic hub with 2pcs sawn dog bone hsp 02003 - http://alii.pub/5v409f

front & rear steering ******* hub + bearings hsp 02016 - http://alii.pub/5uy2md
steel drive cup - http://alii.pub/5uy2pa
front / rear linkages hsp 02012 - http://alii.pub/5uy3pn
steering link hsp 06016 - http://alii.pub/5v3zht
metal ball head screw hsp 02038 - http://alii.pub/5uy5bl
ball head c hsp 06007 - http://alii.pub/5v3zf3
shock ball mount hsp 06023 - http://alii.pub/5v412l
steering a hsp 02025e spare parts - http://alii.pub/5uy5eb
steering arm complete b hsp 02075 - http://alii.pub/5uy5i0
wheel hex nut 12mm drive hubs with pins 02100 - http://alii.pub/5uy67a

front lower suspension arm pin 25x3mm - http://alii.pub/5uy6bd
rear lower arm round pin b 23x3mm - http://alii.pub/5uy6os
front lower shaft pin a hsp 02036 - http://alii.pub/5uy6xq
or you can cut from nails 3mm diameter

e-clipφ2.5 30p for hsp 02037 - http://alii.pub/5uy72s
metal nylon nut m4 hsp 02055 - http://alii.pub/5uy77u

mini micro 2 pin jst xh connector plug 2.54mm - http://alii.pub/5v3zw0
servo extension lead wire cable - http://alii.pub/5v42lm
pins stationery buttons - http://alii.pub/5v42ml

servos:
4 x mg90s - http://alii.pub/5uy5nn
1 x ds3218 - http://alii.pub/5uy5pe

bearings:
3 x 6702zz 15x21x4mm - http://alii.pub/5uy5yx
4 x 623zz 3x10x4mm - http://alii.pub/5vkgcf

screws:
6 x m2x6mm - http://alii.pub/5v3xq8
25 x m3x3mm - http://alii.pub/5v3xt5

30 x m3x10mm - http://alii.pub/5v3xr0
13 x m3x12mm - http://alii.pub/5v40gf

20 x m3x10mm - http://alii.pub/5v41m8

1 x m3x10mm - http://alii.pub/5v41ko
2 x m3x10mm - http://alii.pub/5v419s

29 x m2.6x6mm - http://alii.pub/5v41wj

nails:
10 x diameter 2mm leight min 30mm
20 x diameter 3mm leight min 80mm

magnets:
12 x 12x3x4mm - http://alii.pub/5v42j3
