qvv5zl5 series manifold (air distribution area, valve plate, valve seat, air circuit board) (14 specifications in total)
there are at least two channels running through the manifold plate, which are air inlet and air outlet respectively. the air at the air inlet is supplied by the air source. after the distribution of the manifold plate, the air from the air outlet is connected to the components (such as solenoid valve) that need air in the complete set of equipment through the connection of pneumatic hose, pneumatic connector and other accessories. in this way, a small amount of air supply can supply multiple pneumatic components at the same time. Print Ready: No
